Tecna Rhino New Gen Spot Welder

Code ZX3664P7
Code ZX3664P7
£0.00 £0.00(inc. VAT)
£12,428.00 £14,913.60(inc. VAT)
Save
Earn 0 reward points with this product.
  • Description

    This is the very latest and to date, the most powerful Spot Welding station to come out of Tecna.

    The Rhino has 14000 amps welding power together with a clamping force of 610 daN, this means it currently meets all criteria set by all the vehicle manufacturers .

    The Rhino features 7" digital touch screen display, USB port for data storage, automatic set up of welding pressure by means of the proportional valve and full quality control

    Free days training to PAS125

    • Meets most other VW UK specifications
    • Full Tesla approval
    • Smart plus mode - fully automatic operation
    • Ideal for insurance approved bodyshops
    • 4m or 6m cable option
    • C clamp transformer gun
    • True 360 rotational built in Gyro
    • Super fast arm change

    Rhino Spot Welder Spec

  • Technical Data
    Input voltage400V3 Phase
    Nominal power at 50%kVA19
    Maximum welding powerkVA60
    Maximum secondary currentkA14
    Thermal current 100%kA1.8
    No load secondary voltageV8.7
    Max electrode forcedaN700
    Recognition sensor
    		5
    Protection insulation class
    		IP21
    WeightKg130
