Parweld XTM201i Inverter MIG Welder
The Parweld XTM201i Inverter MIG Welder is a compact, multi-process welding power source designed for professional fabrication, maintenance, and workshop use. Built around modern inverter technology, it delivers a smooth stable DC welding output while maintaining excellent portability and energy efficiency. The unit operates from a standard 230V single-phase supply and produces a maximum output of 200A, making it suitable for light-to-medium fabrication tasks and materials up to approximately 4 mm thickness.
The XTM201i supports multiple welding processes in a single machine, including MIG/MAG, Lift-TIG, and MMA (stick) welding. This versatility allows users to switch between processes depending on the application, making it suitable for workshop fabrication, site work, agricultural repair, automotive tasks, and general maintenance.
A key feature of the XTM201i is its synergic MIG control system. This intelligent function automatically matches the voltage and wire feed speed based on the selected wire size and material settings, simplifying setup and helping maintain consistent arc performance. The system allows both manual and synergic operation for greater control when required.
Additional Features
2T / 4T trigger modes for improved control on longer welds
Compatible with 1 kg (100 mm) and 5 kg (200 mm) wire spools
Forced-air cooling system for improved thermal management
IP23S rated enclosure for increased durability in workshop environments
Compact and portable
5 Year warranty
Supplied as part number XTM201i-P1 which includes the 3m MIG torch and regulator.
- Technical Data
Maximum current 200A DC Spool size 200mm (5kg) 100mm (1kg) Feed set up 2 Roll Wire size 0.8-1.0mm Duty cycle 200A @ 25% Input voltage 230V Min fuse rating 16A Generator size 13 kVA must have AVR Dimensions 469 x 223 x421mm Weight 15.5Kg
