ESAB A50 Lux Welding Helmet

ESAB A50 LUX Welding Helmet Ultimate Clarity and Comfort for Professional Welders.

The ESAB A50 LUX welding helmet combines cutting-edge optical technology with superior comfort and style. Featuring a crystal-clear True Colour lens, fast auto-darkening response, and a wide viewing area, the A50 LUX delivers exceptional visibility and eye protection during MIG, TIG, and MMA welding.

Built for serious welders, the A50 LUX includes:

• True Colour ADF lens for realistic colour perception and reduced eye strain

• Large 100 x 60mm viewing area for maximum awareness and precision

• External grind mode for easy switching between welding and grinding

• Lightweight, ergonomic shell for long-lasting comfort on all-day jobs

• Fully adjustable headgear to ensure a perfect fit

• 50 Lumen-dual LED work light behind the front cover lens

Features

•  Advanced LED work-light with dedicated arc sensor and power supply
•  Easily-accessed LED work-light power button and separate external grind button
•  ADF viewing area: 100 x 60 mm (3.94 x 2.36 in.) with internally-adjustable push-button controls
•  Shade range: DIN 3/513
•  ESAB OpTCS True-Colour Lens Technology
•  Arc sensors: 4
•  Fast switching time of 0.07 millisecond
•  Replaceable CR2450 battery
•  Low battery and grind mode LEDs

Welding Processes

• Oxy Fuel Cutting
•  Plasma Cutting
•  Grinding
•  Welding, GMAW (MIG/MAG)
•  Welding, GTAW (TIG)
•  Welding, PAW -Plasma Arc Welding
•  Welding, SMAW/MMA (Stick)

Technical Data
